LIGHTALL- Focus On LED Screen Field For More Than 10 Years.
leading 3d led screen outdoor company | LIGHTALL
Guided by scientific and technological innovation, LIGHTALL always keeps outward-oriented and sticks to the positive development on the basis of technological innovation. 3d led screen outdoor We will do our best to serve customers throughout the whole process from product design, R&D, to delivery. Welcome to contact us for further information about our new product 3d led screen outdoor or our company.LIGHTALL 3d led screen outdoor is designed and optimized exclusively. Many factors which affect its performance such as materials, air circulation parts, housing finish are all considered during its design.
CURVED | QUICK | SOLID
Adivancedl gluing technology,with a certain thickness and strength, anti-scratch,anti-skidding
WE ARE MORE PROFESSIONAL
Not only for indoor and outdoor event use, pitch 2.6mm LED panel is 1/16 scan with 7680Hz high refresh rate, high contrast ratio and wide color gamut, suitable for XR stage and vitual production studio. The LED panel can be spliced to 90° to meet the needs of different application.
Support Cuved lnstallation
Product Usage
Adjustable brigtness for indoor and ouldoor use Such as movie production, aviation show, experience paviion,exhibition of linearts,muscum of art, science museum
Front Maintenance Design
*Vacuum tool is recommend for maintenance.
*LED Modules are pasted by strong magnet. It is complete front service.
*Magnets module support front service. The panel back cover can be
opened from the back side for rear service purpose as well
PERFECT DISPLAY PERFORMANCE
High brightness, high refresh rate,high gray scale
STACKING AND HANGING
SYSTEM OPTIONAL
parameter
| Pixel Pitch | P1.95 | P2.315 | P2.604 |
| LED Type | SMD1515 | SMD1515 | SMD1515 |
| Physical Density(dots/m2) | 262144 | 186624 | 147456 |
| Module Resolution | 128×128 | 108×108 | 96×96 |
| Module Size (WxH) | 250×250 | 250×250 | 250×250 |
| cabinet Size | 500×500×84.5 | 500×500×84.5 | 500×500×84.5 |
| Cabinet Resolution | 256×256 | 216×216 | 192×192 |
| Module QTY /Cabinet (WxH) | 2×2 | 2×2 | 2×2 |
| Cabinet Weight(kg) | 8 | 8 | 8 |
| Maintenance Mode | Front/Back maintenance | Front/Back maintenance | Front/Back maintenance |
| cabinet Material | Die-casting Aluminum | Die-casting Aluminum | Die-casting Aluminum |
| Brightness | ≥1500 | ≥1500 | ≥1500 |
| Viewing Angle(H/V) | 160°/160° | 160°/160° | 160°/160° |
| The best viewing distance | 2-50m | 3-50m | 3-50m |
| Contrast Ratio | 10000:1 | 10000:1 | 10000:1 |
| Frame Frequency | 60/120 | 60/120 | 60/120 |
| Drive Mode | Static,1/8 Scan | Static,1/9 Scan | Static,1/8 Scan |
| Refresh Rate(Hz) | 7680 | 7680 | 7680 |
| Grey Level | 16 bit | 16 bit | 16 bit |
| lP Grade | IP 31 | IP 31 | IP 31 |
| Max Power Consumption(W/m2) | 920 | 920 | 920 |
| Average Power Consumption(W/m2) | 200-300 | 200-300 | 200-300 |
| lnput Power | AC90-264V,47-63Hz | ||
| Working Temperature/Humidity(°C/RH) | -20~60°C / 10%~85% | ||
| Storage Temperature/Humidity(C/RH) | -20~60°C / 10%~85% | ||
| Cert. | CCC / CE/ RoHS / FCC / CB /TUV / IEC | ||
Established in 2013, Shenzhen Lightall Optoelectronic Technology Co. Ltd. Is a Professional LED Display Manufacturer, Who Is Integrated in R&d, Manufacture, Marketing and After-Sale Service.
