LIGHTALL- Focus On LED Screen Field For More Than 10 Years.
leading solutions creative video wall factory | LIGHTALL
After years of solid and rapid development, LIGHTALL has grown into one of the most professional and influential enterprises in China. creative video wall Today, LIGHTALL ranks the top as a professional and experienced supplier in the industry. We can design, develop, manufacture, and sell different series of products on our own combining the efforts and wisdom of all our staff. Also, we are responsible for offering a wide range of services for customers including technical support and prompt Q&A services. You may discover more about our new product creative video wall and our company by directly contacting us.The design of LIGHTALL is a consequence of many combined parameters. Geometry, materials, surface area design, and air velocity are all seriously considered in enhancing the performance of the product.
Product Description
Column Installation
Fixed and Rental LED Display
For more column design in stage, shopping mall,
enterprise, etc.
High Refresh Rate & High Grayscale
Air Suction Front Maintenance Tool
Specification
| Item | P3.91 | Chip | Epstar |
| Chip size | Red 9 mil, Green 12. Blue 12mil | Light type | SMD |
| Pixel Pitch | 3.91mm | Size | 500mm*500mm |
| Resolution | 128*128 pixel | Density of pixel | 65410 pixels/sqm |
| Pixel configuration | 1R1G1B | Red wavelength | 625±2nm |
| Green wavelength | 525±2nm | Blue wavelength | 470±2nm |
| Colors | 16777216 | Best viewing distance | ≥3m |
| viewing angle | 120°/90° | Maximum power consumption | 20W |
| Brightness | >1200 cd/sqm | Gray scale | 16bits per color |
| Color temperature | 6500k | Control method | Synchronization or Asynchronization |
| Driving method | 1/16 scanning | Frame frequency | 60Hz |
| Refresh frequency | ≥600Hz | Working Voltage | DC5V |
| IP grade | IP54 | Warranty | 3 years |
| Life Span | 100,000hours | Certificate | CCC, FCC, ROHOS, CE |
Established in 2013, Shenzhen Lightall Optoelectronic Technology Co. Ltd. Is a Professional LED Display Manufacturer, Who Is Integrated in R&d, Manufacture, Marketing and After-Sale Service.
